LEVIN / PROFESSIONAL OUTDOOR LIGHTING
Give outdoor spaces a distinctive architectural
identity with the LEVIN Angular Bollard Light.
Its sculptural, faceted body features a recessed
illuminated section that combines contemporary
geometric design with controlled low-level
landscape lighting.
Available in 600mm and 800mm heights, this
5W IP65-rated bollard offers three white-light
colour temperatures, a compact 76 × 76mm
body profile and three exterior finish options.
01 / MODEL SELECTION
The Angular Bollard Light is available in two
height configurations. Both share the same
5W lighting specifications, angular design,
material construction and 76 × 76mm body profile.
CODE 2113
A compact architectural bollard designed
for low-level exterior lighting concepts,
garden paths and contemporary landscapes.
CODE 2114
A taller version of the same faceted design,
offering a more prominent architectural
presence along outdoor circulation areas.
Height is the confirmed dimensional difference
between Codes 2113 and 2114. Both models
maintain a 5W rated power and share
the published electrical and optical specifications.
02 / LIGHTING PERFORMANCE
The angular body incorporates a recessed
illuminated section, directing light towards
adjacent ground and landscape surfaces
while keeping the optical component integrated
into the sculptural fixture design.
LIGHT DISTRIBUTION
The optical component is positioned
within the faceted body to provide
controlled, low-level exterior lighting.
COLOUR TEMPERATURE
Choose between 3000K warm white,
4000K neutral white and 6000K
cool white configurations.
COLOUR RENDERING
Both height configurations feature
a published colour rendering index
of Ra ≥80.
A numerical beam angle, luminous flux and
adjustable optical mechanism are not specified
in the published technical information.
03 / TECHNICAL DATA
Compare the two LEVIN Angular Bollard Light
configurations to select the appropriate
height for your landscape or architectural
exterior lighting project.
| Specification | Code 2113 | Code 2114 |
|---|---|---|
| Product Type | Angular Bollard Light | Angular Bollard Light |
| Rated Power | 5W | 5W |
| Colour Temperature | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K |
| CRI / Ra | ≥80 | ≥80 |
| Protection Rating | IP65 | IP65 |
| Input Voltage | AC100–240V | AC100–240V |
| Dimensions | 76 × 76 × 600mm | 76 × 76 × 800mm |
| Working Temperature | -15°C to +50°C | -15°C to +50°C |
| Body Material | Aluminium | Aluminium |
| Optical Component | Lens | Lens |
| Body Finishes | Matt Black / Matt White / Dark Grey | Matt Black / Matt White / Dark Grey |
| Warranty | 3 Years | 3 Years |
Specifications are based on the published
LEVIN product information. LED chip manufacturer,
luminous flux, numerical beam angle and driver
specifications are not provided.
04 / DESIGN & DIMENSIONS
Unlike a conventional straight-sided bollard,
the Angular Bollard Light features a geometric
aluminium body with a distinctive faceted profile.
Its recessed illuminated section becomes part
of the overall architectural composition,
creating visual depth without requiring
a separate externally mounted lighting head.
Both models share a 76 × 76mm body profile
and are available in matt black, matt white
and dark grey finishes.
TALLER CONFIGURATION
800 mm
AVAILABLE HEIGHTS
600 / 800 mm
Shared body profile: 76 × 76mm
05 / APPLICATIONS
Combining low-level illumination with a
distinctive geometric form, the Angular Bollard
Light is an option for exterior projects where
the fixture itself contributes to the landscape design.
Garden Pathways
Introduce low-level illumination and
sculptural architectural detail along
suitable garden paths.
Villa Landscapes
Complement contemporary residential
architecture, outdoor circulation
areas and landscaped courtyards.
Hospitality Exteriors
Create a consistent decorative lighting
language for selected hotel gardens,
pedestrian areas and commercial landscapes.
Final fixture spacing, lighting levels and
installation details should follow the
individual project’s requirements. Confirm
site suitability and protect all electrical
connections during outdoor installation.
06 / PRODUCT QUESTIONS
Both models share the same 5W lighting
specifications and 76 × 76mm body profile.
Code 2113 is 600mm high, while Code 2114
has an 800mm height.
Both Angular Bollard Light models
have a rated power of 5W.
Both models are available in 3000K,
4000K and 6000K fixed white-light options.
Yes. Both configurations have an IP65
protection rating and are intended
for appropriate exterior installations.
Codes 2113 and 2114 support an
AC100–240V input voltage range.
An adjustable lighting mechanism is not
listed for this product. Illumination
is integrated into the angular body
through a recessed optical section.
The technical specifications list
an aluminium body and an integrated lens.
The listed finishes are matt black,
matt white and dark grey.
The published working temperature
is -15°C to +50°C.
Yes. Both models include a
three-year LEVIN warranty.
EXPLORE LEVIN
Discover additional outdoor fixtures in the
LEVIN Landscape Lighting Collection
for pathways, villa gardens and contemporary
exterior lighting projects.
For general information about LED lighting
technology, explore the
U.S. Department of Energy LED Lighting Guide
.
LEVIN / PROJECT SUPPORT
Planning a residential or commercial exterior
lighting project? Contact LEVIN for assistance
selecting the appropriate Angular Bollard Light
height, colour temperature and housing finish.
| Rated power | 5 W |
|---|---|
| Light colour / CCT | 3000K, 4000K, 6000K |
| IP rating | IP65 |
| CRI | ≥ 80 |
| Finish | Black, Grey, White |
| Material | Aluminium |
| Input voltage | 240 V |
